Mitra Krida Mandiri (MKM)

Sonic 150R

Sonic 150R

Regular price Rp 26.210.000
Regular price Sale price Rp 26.210.000
Sale Sold out
View full details

Motor Specifications

Machine

  • Machine Type4 Stroke, DOHC - 4 Valves
  • Machine Capacity149.16cc
  • Fuel Supply SystemPGM-FI
  • Diameter X Step57.3 x 57.8 mm
  • Transmission TypeManual, 6 - Speed
  • Compression Ratio11.3:1
  • Maximum Power11.8 kW (16.0 PS) / 9,000 rpm
  • Maximum Torque13.5 Nm (1.38 kgf.m) / 6,500 rpm
  • Starter TypePedals & Electrics
  • Clutch TypeMultiple Wet Clutch Coil Spring
  • Engine Cooling SystemLiquid Cooled with Auto Fan
  • Gear Shift Pattern1 - N - 2 - 3 - 4 - 5 - 6

Frame & Legs

  • Frame TypeTwin Tube Steel
  • Front Suspension TypeTelescopic
  • Rear Suspension TypeSwing Arm With Single Suspension
  • Front Tire Size70/90-17 38P (Tubeless)
  • Rear Tire Size80/90-17 50P (Tubeless)
  • Front BrakeHydraulic Disc
  • Rear BrakeHydraulic Disc

Dimensions & Weight

  • Length x width x height1,941 x 669 x 977 mm
  • Seat Height762mm
  • Wheelbase1,275mm
  • Lowest Distance to Ground140mm
  • Curb Weight114 kg

Capacity & Electricity

  • Fuel Tank Capacity4 liters
  • Lubricating Oil Capacity1.1
  • Battery Type or AkiMF Wet 12V 5Ah
  • Ignition SystemFull Transisterized
  • Spark Plug TypeNGK MR9C-9N or ND U27EPR-N9
