Mitra Krida Mandiri (MKM)

BeAT Street

BeAT Street

Regular price Rp 20.410.000
Regular price Sale price Rp 20.410.000
Sale Sold out
View full details

Motor Specifications

Machine

  • Machine Type4 – Step, SOHC, eSP
  • Step Volume109.5cc
  • Fuel Supply SystemInjection (PGM-FI)
  • Diameter X Step47 x 63.1mm
  • Transmission TypeAutomatic, V-Matic
  • Compression Ratio10.0 : 1
  • Maximum Power6.6 kW (9.0 PS) / 7,500 rpm
  • Maximum Torque9.3 Nm (0.95 kgf.m) / 5,500 rpm
  • Starter TypeElectric & Kick Starter
  • Clutch TypeAutomatic, Centrifugal, Dry Type

Frame & Legs

  • Frame TypeUnderbone - eSAF (enhance Smart Architecture Frame)
  • Front Suspension TypeTelescopic
  • Rear Suspension TypeSwing Arm with Single Shock Absorber
  • Front Tire Size80/90 – 14 M/C – Tubeless
  • Rear Tire Size90/90 – 14 M/C – Tubeless
  • Front BrakeHydraulic Disc with Single Piston
  • Rear BrakeDrum
  • Braking SystemCombi Brake System

Dimensions & Weight

  • Length x width x height1877 x 742 x 1030 mm
  • Seat Height740mm
  • Wheelbase1,256mm
  • Lowest Distance to Ground147mm
  • Curb Weight89 kg

Capacity & Electricity

  • Fuel Tank Capacity4.2 L
  • Lubricating Oil Capacity0.65 Liter (Periodic Replacement)
  • Battery Type or AkiBeAT Street MF 12V-3Ah
  • Ignition SystemFull Transisterized
  • Spark Plug TypeNGK MR9C-9N
